Digital pH sensor
Memosens CPS31D

Memosens CPS31D - Digital pH sensorfor potable water and swimming pools ©Endress+Hauser
Memosens CPS31D for pH compensation in disinfection processes ©Endress+Hauser

The pH-value of a liquid can be calculated using the potentiometric measurement principle. This video shows what it is about and how this measuring principle works.

Memosens converts the measured value to a digital signal and transfers it to the transmitter without a contacting connection. This video shows how Memosens optimizes process control and maintenance.

Memosens glass electrode for application in drinking water and swimming pools

Memosens CPS31D is the digital expert for pH compensation in disinfection processes. Its three diaphragms make it suitable for minimum conductivity while its low drift guarantees stable measurement. The sensor makes sure that swimming pool water is agreeable and drinking water tasteful. Thanks to Memosens technology, CPS31D combines maximum process and data integrity with simple operation. It resists corrosion and moisture, enables lab calibration and facilitates predictive maintenance.

  • 利点

    • Reliable measurement at minimum conductivity thanks to three diaphragms

    • Low drift by very low level of ion depletion in electrolyte

    • Optional salt ring for extended operating time

    • Maximum process safety through non-contact inductive signal transmission

    • ...

  • アプリケーション

    • Drinking water

    • Swimming pool water

    • pH compensation for free chlorine measurement

機能と仕様

戻る

Details

  • 測定原理

    ガラス電極

  • アプリケーション

    飲料水およびスイミングプール、遊離塩素を測定するためのpH補正

  • 特性

    標準的な水アプリケーション、長寿命

  • 測定範囲

    pH 1 - 12

  • 測定原理

    ダイアフラム1個または3個付きのゲル充填リファレンス、ソルトリング(オプション)。

  • 構造

    シャフト長 120 mm、温度計付き

  • 材質

    ガラス / セラミック

  • 外形寸法

    シャフト長 120 mm

  • プロセス温度

    0 ... 80 °C (32 ... 176 °F)

  • プロセス圧力

    0.1 ... 0.4 MPa 絶対圧 (15 ... 60 psi)

  • 温度センサ

    NTC 30k

  • 防爆規格適合証明書

    なし

  • 接続

    Memosens

  • 保護等級

    IP68
